VK-OFL Online Flat Surface Labeller Machine
For automatic labeling on side flat drum, box, pallet and any big heavy product for the pharmaceuticals, daily chemicals, food & beverages industries. The labeller will automatically detects the label size and set the appropriate labeling parameters, a very useful feature for users with multiple products to label.
Output Speed: 20-100 pieces/minute depends on label and bottle size
Dimension: 1100(L) 900 (W) 1650 (H) mm
Function:
1. Machine for automatic labeling on any big objects, such as pallet, box, carton, big drum and so on, for the pharmaceuticals, daily chemicals, food & beverages industries.
2. Machine stick label from left or right side of object. It not has conveyor, it is very smart, put along with conveyor, it can work.
3. The labeler automatically detects label size, and stick label on object. worker can choose saved parameters, a very useful feature for users with multiple products to label.
4. It is an optimal combination of speed, accuracy, stability, GMP standards, ease of use, and flexibility.
5. PLC and HMI control system are all English, easy operation, servo motor for label feeding power.
6. High labeling accuracy, fast labeling speed, long-time using.
7. Deta code printer are all optional.
Technical parameter:
Model | VK-OFL |
Capacity (PCS/min) | 0-100 (depond on label size) |
Conveyor | not have conveyor, put on line,it can be work, very smart |
Labeling error | < ±1 mm |
The inner diameter of label roll | 76 mm |
The outer diameter of label roll | 360 mm(max) |
Suitable for label size | W:15-310mm, L:20-300mm |
Suitable size of labeling objects | any size big drum, carton, box, pallet |
Power supply(In China) | AC220V 50/60HZ 1ph (customized) |
Power | 350 W |
Weight | 150 KG |
Machine size | 1100(L) 900 (W) 1650 (H) mm |
1. It is an optimal combination of speed, accuracy, stability, GMP standards, easy use, and flexibility.
2. Backed by a strong engineering team who is ready to provide custom solutions for the unique production needs of different customers.
3. PLC combined with human/machine interface digital LCD touch screen controller.
4. Labeling speed is automatically synchronized with conveyor speed to ensure quality labeling.
5. The kind machine without conveyor, it only put along of existing conveyor, it can working, very convenient and smart.
